Fully Automatic Terminal Cross Section Analyzer
WYD-3000Z-DC300
Send Email Details
Equipment Function Overview
The fully automatic terminal cutting and grinding machine is mainly used for the preliminary cutting and rough grinding of the cross-section detection of wire harness terminals in electronic circuits, automotive industries, etc. The equipment is equipped with a set of fixture pads as standard, and can use cutting discs to cut terminals of different materials or other small workpieces. The cutting speed is fast and the grinding speed is fast, which greatly improves the process efficiency and efficiency. The whole set of fully automatic terminal cutting and grinding machine system consists of terminal cutting equipment, grinding equipment, corrosion cleaning, cross-section image acquisition system, wire harness terminal picture measurement and analysis system and other units.
The various measured data and the compression rate of the core wire and the bright cross-section graphics are transmitted to Excel and WORD documents through the software. The evaluation report can be output efficiently.
The whole system consists of terminal cutting, grinding equipment (all-in-one machine), corrosion (special), microscopic imaging system, terminal analysis system, standard identification ruler (0.1mm), LED light source, computer and other units. The terminal microscopic analysis system can observe objects with a strong three-dimensional sense, clear imaging, and a long working distance. It adopts ergonomic design, modular combination, and assembly line workflow to make operation more convenient and quick. It saves time and effort, and greatly improves the speed of terminal section quality inspection.
