Semi-Automatic Metallographic Grinding/Polishing Machine

MP-2DSH
This grinding and polishing machine is a double-disc double-control double-motor semi-automatic metallographic grinding/polishing machine. It can be operated by two people at the same time. The grinding and polishing head can be used for the preparation of 1-4 samples. Single-point pressurization can use different pressures for each sample, greatly improving work efficiency. It is suitable for pre-grinding, grinding and polishing operations on metallographic samples. The host can achieve stepless speed change and random switching of steering. The left and right grinding and polishing discs can obtain a speed between 50-1500 rpm, making this machine more widely applicable. It is an indispensable equipment for users to make metallographic samples. This machine is equipped with a universal cooling device, which can cool the sample during pre-grinding to prevent the metallographic structure from being damaged due to overheating of the sample. The machine is easy to use, safe and reliable, and is an ideal sample preparation equipment for factories, scientific research institutions and laboratories of colleges and universities.

Operating voltage

220V  50HZ

Grinding and polishing disc diameter

φ203mm

Speed

50-1500 rpm

Electric Motor

300W

Product size

650×510×350mm

Packing size

800×800×430mm

Weight

45kg

Packing weight

60kg

Grinding and polishing head parameters

power supply

220V  50HZ

Gripper size

30mm, 40mm (choose one)

Speed

50r/min

Pressurization method

Single point pressurization

Number of pressure heads

0~40N

Number of pressure heads

1~4pc

Net weight

16kg

Size

400*450*200mm

Standard accessories

Bright red velvet

2 pieces

Metallographic sandpaper

Ø200 #320 #600 #1500 #3000 3 pieces each

Water inlet pipe

1 root

Drain

1 root

Clamp

Ø32  1pc

Alumina polishing powder

50g/1 bottle

Aluminum buckle ring

2pc

Water retaining ring

2pc

Brush

1pc

Product Brochure

One copy

Product Certificate

One copy

Product Packing List

One copy

×
