Double Disc Double Control Grinding/Polishing Machine

Double Disc Double Control Grinding/Polishing Machine

MP-2DC

Consult

Features
Technical Indicators
Overall Dimension

This grinding and polishing machine is a double-disc, double-control, double-motor machine with a high-definition touch screen control system. It can be operated by two people at the same time and is suitable for pre-grinding, grinding and polishing of metallographic specimens. This machine can achieve infinitely variable speed and random switching of steering. The left and right grinding and polishing discs can obtain a speed between 50-1500 rpm, making this machine more widely applicable. It is an indispensable equipment for users to make metallographic specimens. This machine is equipped with a cooling device, which can cool the specimen during pre-grinding to prevent the metallographic structure from being destroyed due to overheating of the specimen. The machine is easy to use, safe and reliable, and is an ideal sample preparation equipment for factories, scientific research institutions and laboratories of colleges and universities.
Body material Plastic steel shell body Control High-definition touch screen control system Input voltage 220V 50HZ Spindle motor Brushless motor 300W*2 Machine power 600W Grinding and polishing disc diameter 200MM (8') double reel, double control Grinding and polishing disc speed 50-1500r/min Product size 650mm×500mm×350mm Packing size 770mm×620mm×380mm (outer box + station board) Product Net Weight 34 KG Product Gross Weight 50 KG (including box and stand) Customized colors White/Black Standard accessories Bright red velvet 2 pieces Metallographic sandpaper Ø200 #320 #600 #1500 #3000 3 pieces each Water inlet pipe 1 root Drain 1 root Clamp Ø32 1pc Alumina polishing powder 50g/1 bottle Aluminum buckle ring 2pc Water retaining ring 2pc Brush 1pc Product Brochure One copy Product Certificate One copy Product Packing List One copy

Body material	Plastic steel shell body
Control	High-definition touch screen control system
Input voltage	220V 50HZ
Spindle motor	Brushless motor 300W*2
Machine power	600W
Grinding and polishing disc diameter	200MM (8') double reel, double control
Grinding and polishing disc speed	50-1500r/min
Product size	650mm×500mm×350mm
Packing size	770mm×620mm×380mm (outer box + station board)
Product Net Weight	34 KG
Product Gross Weight	50 KG (including box and stand)
Customized colors	White/Black
Standard accessories
Bright red velvet	2 pieces
Metallographic sandpaper	Ø200 #320 #600 #1500 #3000 3 pieces each
Water inlet pipe	1 root
Drain	1 root
Clamp	Ø32 1pc
Alumina polishing powder	50g/1 bottle
Aluminum buckle ring	2pc
Water retaining ring	2pc
Brush	1pc
Product Brochure	One copy
Product Certificate	One copy
Product Packing List	One copy
