Single Disc Grinding And Polishing Machine

MP-1SS

This grinding and polishing machine is a single-disc desktop machine, manually controlled, simple and practical to operate, with a practical and elegant appearance. It uses 304 stainless steel sheet metal electroplating technology and is suitable for pre-grinding, grinding and polishing operations on metallographic specimens. The grinding and polishing disc of this machine is powered by a brushless motor, which can provide a precise speed of 50~1500 rpm, stable operation and low noise. This machine can be equipped with an external dripping device, and the dripping time and pause time can be freely set, which greatly improves the sample preparation effect. The machine is easy to use, safe and reliable, and is an ideal sample preparation equipment for factories, scientific research institutions and laboratories of colleges and universities.
Body type Desktop Number of clamps None Pressure mode Manual Single point pressure Manual Operation mode Manual mode Control system Manual control Polishing speed 50-1500 rpm (stepless speed regulation) Grinding head speed None Abrasive addition External Grinding disc motor 750W 220V brushless motor Grinding head motor None Grinding sample diameter Grinding disc diameter 300mm Overall dimensions 730*620*780mm Power supply 220V/50HZ/750W

Body type	Desktop
Number of clamps	None
Pressure mode	Manual
Single point pressure	Manual
Operation mode	Manual mode
Control system	Manual control
Polishing speed	50-1500 rpm (stepless speed regulation)
Grinding head speed	None
Abrasive addition	External
Grinding disc motor	750W 220V brushless motor
Grinding head motor	None
Grinding sample diameter
Grinding disc diameter	300mm
Overall dimensions	730620780mm
Power supply	220V/50HZ/750W
